Switch technical Characteristics)：
| ITEM | Technical parameter | Value | |
| 1 | Electrical Rating | 5(2)A 250VAC | |
| 2 | Operating Force | 1.0～5.0N | |
| 3 | Pretravel | 0.6～1.5mm | |
| 4 | Contact Resistance | ≤50mΩ( Initial value) | |
| 5 | Insulation Resistance | ≥100MΩ(500VDC) | |
| 6 | Dielectric Voltage | between non-connected terminals | 500V/0.5mA/60S |
| between terminals and the metal frame | 1500V/0.5mA/60S | ||
| 7 | Electrical Life | ≥10000 cycles | |
| 8 | Mechanical Life | ≥100000 cycles | |
| 9 | Operating Temperature | -25～85℃ | |
| 10 | Operating Frequency |
Electrical:15 cycles
Mechanical:60 cycles |
|
| 11 | Vibration Proof |
Vibration Frequency：10～55HZ；
Amplitude：1.5mm; Three directions:1H |
|
| 12 | Solder Ability: More than 80% of immersed part shall be covered with solder |
Soldering Temperature：235±5℃
Immersing Time：2～3S |
|
| 13 | Solder Heat Resistance |
Dip Soldering：260±5℃ 5±1S
Manual Soldering：300±5℃ 2～3S |
|
| 14 | Safety Approvals | UL、CSA、CQC | |
| 15 | Test Conditions |
Ambient Temperature：20±5℃
Relative Humidity：65±5%RH Air Pressure：86～106KPa |
|
